Submercible Pump Test Rig
Product Code : EL-HML-11059
The Submersible Pump Test Rig from Lab Exports is a hydraulic machine lab setup that lets students study the performance of a submersible pump, determining its overall and pump efficiency and plotting head vs. discharge characteristic curves.
Specifications
| Pump | Submersible pump, 1 HP capacity |
| Supply Tank | 90 litre capacity, stainless steel |
| Measuring Tank | 60 litre capacity, stainless steel, fitted with piezometer tube and scale |
| Piping | GI / PVC |
| Stop Watch | Electronic |
| Control Panel | Complete electrical instrumentation |
Key Features
- Submersible pump coupled with electrical motor for direct performance testing
- Pressure and vacuum gauges on delivery and suction side for head measurement
- Closed-loop water circulation in a compact, stand-alone unit
- Stainless steel tanks and wetted parts for corrosion resistance
- Electronic stop watch and measuring tank for accurate flow rate readings
- MS Excel sample calculation program available on demand
Applications
The Submersible Pump Test Rig is used in hydraulic machinery laboratories to study submersible pump performance, helping students determine overall and pump efficiency and plot head vs. discharge and pump efficiency vs. discharge characteristic curves.
Why Choose Lab Exports
Lab Exports is a trusted manufacturer and exporter of engineering lab equipment including a complete range of Hydraulic Machine Lab apparatus for engineering colleges and technical institutes. Every unit is built for classroom durability, measurement accuracy and long-term reliability, backed by responsive after-sales support.
Related Products in Hydraulic Machine Lab
- Jet Pump Test Setup
- Gear Pump Test Setup
- Reciprocating Pump Test Setup
- Hydraulic Machine Lab Equipment
- Engineering Lab Equipment
Frequently Asked Questions
Q1. What does the Submersible Pump Test Rig measure?
It measures the overall efficiency and pump efficiency of a submersible pump, allowing students to plot head vs. discharge and efficiency vs. discharge curves.
Q2. What capacity pump is used?
A 1 HP submersible pump coupled with an electrical motor is used in the test rig.
Q3. How is discharge measured?
Discharge is measured using a stainless steel measuring tank with a piezometer tube and scale, along with an electronic stop watch.
Q4. What are the tank capacities?
The supply tank has a 90 litre capacity and the measuring tank has a 60 litre capacity, both in stainless steel.
Q5. What utilities are required to operate the rig?
It requires a 230V ±10VAC, 50Hz, single-phase electric supply with proper earthing, and a tap water connection.
