Hydraulic Bench Apparatus
Product Code : EL-HML-11060
Quick answer: The hydraulic bench apparatus is a self-contained, water-recirculating base unit for fluid mechanics experiments such as hydrostatic pressure, flow over weirs, Bernoulli's theorem, impact of jet and orifice discharge. A 1 HP centrifugal pump feeds the 1060 x 650 mm top tray, and a 40 litre measuring tank gives volumetric flow. Lab Exports manufactures it in Delhi for engineering colleges, polytechnics and TVET institutes.
Specifications
| Component | Specification |
|---|---|
| Top tray | 1060 x 650 mm |
| Pump | Centrifugal, 1 HP |
| Flow control | Flow control valve |
| Measuring tank | 40 litres, stainless steel, with level indicator and scale |
| Sump tank | 120 litres, stainless steel, with drain valve and overflow |
| Finish | Powder coated structure |
| Floor area | 1.75 m x 1.50 m |
| Services | 220 V AC, 50 Hz, single phase; drain connection |
How the hydraulic bench is used
Most first courses in fluid mechanics need a steady, measurable water supply, and the hydraulic bench provides it in one self-contained unit. The centrifugal pump draws water from the sump tank and sends it through the flow control valve to the experiment placed on the top tray. The water then drains to the measuring tank and back to the sump, so the same water is used again and no mains water is needed during a practical.
Flow is measured volumetrically: time how long the level in the measuring tank takes to rise by a set amount on the scale and divide the volume collected by the time, Q = V / t. The same bench and method serve the accessories for hydrostatic pressure, flow over weirs, Bernoulli's theorem, flow meter demonstration, impact of jet and orifice discharge.
- Fill the sump tank and place the chosen accessory on the top tray.
- Start the pump and set the flow with the flow control valve.
- Read the level indicator and scale on the measuring tank while timing the rise.
- Take the experiment readings, then change the flow and repeat.
Key features
- Self-contained, water-recirculating base unit for several fluid mechanics experiments
- 1060 x 650 mm top tray to hold the experiment accessories
- 1 HP centrifugal pump with flow control valve for different flow rates
- 40 litre stainless steel measuring tank with level indicator and scale
- 120 litre stainless steel sump tank with drain valve and overflow
- Powder coated structure on a floor area of 1.75 m x 1.50 m
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the hydraulic bench at its works in Laxmi Nagar, Delhi, and supplies it to engineering colleges, polytechnics and TVET institutes in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Hydraulic Machine Lab products
- Submersible Pump Test Rig (EL-HML-11059)
- Jet Pump Test Setup (EL-HML-11058)
- Hydraulic Ram Test Setup (EL-HML-11057)
- Gear Pump Test Setup (EL-HML-11056)
- Reciprocating Pump Test Setup (EL-HML-11055)
- Multi Stage Centrifugal Pump Test Setup (EL-HML-11054)
The full range is in the Hydraulic Machine Lab section of the Engineering Lab range.
