Portable Diaphragm Type Vacuum Pump cum Air Compressor, Oil Free, Light Weight
Product Code : EL-POM-10365
Quick answer: This portable diaphragm vacuum pump cum air compressor is an oil-free, double-stage unit that can draw a low vacuum or deliver low-pressure air, for vacuum demonstrations, filtration and other bench work where oil vapour must be kept away from samples. It is lightweight, runs quietly and comes with cord and plug. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Item | Specification |
|---|---|
| Type | Diaphragm, double-stage |
| Lubrication | Oil-free |
| Function | Low vacuum pump cum low-pressure air compressor |
| Weight | Lightweight, portable |
| Noise | Low-noise operation |
| Supplied as | Complete with cord and plug |
Vacuum level and air flow figures are not listed here; include the values needed in the enquiry.
How it is used
A diaphragm pump moves air by flexing a membrane, driven by its motor, with valves that let air into and out of the pumping chamber. No oil is used to seal the mechanism, so nothing can creep back into the vessel being evacuated, and glassware and samples stay clean. Two pumping stages in series reach a lower pressure than a single stage of the same size.
Used from its outlet, the same unit works as a small compressor. One pump can therefore evacuate a bell jar or a filter flask for one experiment and then supply low-pressure air for another, which suits a school laboratory that needs both on the same bench.
- Place the pump on a level bench and connect it to the mains with the cord and plug supplied.
- Attach the vessel to be evacuated, or the apparatus to be supplied with air, using suitable tubing.
- Switch on and let the pump run until the required vacuum or pressure is reached.
- Switch off and release the vacuum slowly before disconnecting the tubing.
Key features
- Oil-free diaphragm design that avoids contaminating samples with oil vapour
- Double-stage pumping for low vacuum work
- Dual function: vacuum pump and air compressor in one unit
- Lightweight and easy to carry between benches and rooms
- Low-noise running suited to teaching rooms
- Supplied complete with cord and plug
Documentation and supply
Installation instructions and a manual are supplied with the pump. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the diaphragm vacuum pump cum air compressor at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Properties of Matter products
- Bell Experiment Apparatus (EL-POM-10364)
- Magdeburg Hemispheres (EL-POM-10366)
- Air Pump (Vacuum Pump with Aluminium Plate) (EL-POM-10363)
- Fluid Pressure Apparatus (Spouting Cylinder) (EL-POM-10367)
- Pendulum Bobs or Spheres (EL-POM-10362)
- Simple Pascal Law Experiment (Pressure String) (EL-POM-10368)
The full range is in the Properties of Matter section of the Physics Lab range.
Frequently asked questions
What is the advantage of an oil-free diaphragm vacuum pump?
It needs no oil and cannot contaminate samples or glassware with oil vapour, which matters in sensitive experiments and in vacuum filtration.
Can the pump be used as an air compressor?
Yes. It works both as a low vacuum pump and as a low-pressure air compressor.
What is supplied with the pump?
The pump is supplied complete with cord and plug.
What is the price of the diaphragm vacuum pump cum air compressor?
Prices are not published on the website. Add the diaphragm vacuum pump cum air compressor to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-POM-10365 and the quantity, to receive a quotation.
Does Lab Exports manufacture the diaphragm vacuum pump cum air compressor?
Yes. Lab Exports manufactures the diaphragm vacuum pump cum air compressor at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-POM-10365.
Request a quote
Email [email protected] with the house code EL-POM-10365 and the quantity, or add the diaphragm vacuum pump cum air compressor to the Enquiry Cart with the Add To Cart button on this page. Tender buyers can also see the Tenders and OEM page.
