Meker Burner Heavy Base
Product Code : EL-B-10657
Quick answer: The Meker Burner with heavy base is a high-temperature gas burner on a wide 80 mm die-cast metal base, with a 25 mm perforated top plate on a nickel-plated tube and a rotatable air regulator around the jet. It is used for strong, even heating such as igniting precipitates and heating crucibles. Lab Exports manufactures it in Delhi for school, college and research laboratories.
Specifications
| Item | Specification |
|---|---|
| Type | Meker burner, heavy base |
| Base | Heavy, wide die-cast metal, 80 mm diameter |
| Burner tube | Nickel plated |
| Top plate | Perforated, 25 mm diameter |
| Air control | Rotatable air regulator around the jet |
| Gas inlet | Riffled (serrated) |
| Overall height | 150 mm |
How it is used
For high-temperature work the burner has to stay put: a crucible on a pipeclay triangle or a heavy vessel on a tripod above it should not be disturbed if the gas tube is knocked. The heavy, wide die-cast base of this Meker burner gives that stability, and its 150 mm height keeps the flame at a practical working level under a tripod.
The rotatable air regulator around the jet sets how much air is drawn in with the gas. Opening it until the flame over the perforated plate becomes a close bed of small blue cones gives the hottest, most even heat; closing it gives a softer flame. The perforated top plate keeps the flame stable over long heating runs such as ignition of precipitates or heating crucibles to constant mass.
- Stand the burner on a heat-resistant surface and connect the riffled inlet to the gas tap.
- Close the air regulator, open the gas and light the burner.
- Turn the air regulator gradually until the plate shows an even bed of blue flames.
- Set the crucible or vessel on a support above the plate and heat as required.
- Close the gas tap after use and let the burner cool on the bench.
Key features
- Heavy, wide 80 mm die-cast base for stability
- Rotatable air regulator around the jet for flame control
- 25 mm perforated top plate for a stable, even high-temperature flame
- Nickel-plated burner tube
- Riffled gas inlet for a secure tube connection
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Meker burner with heavy base at its works in Laxmi Nagar, Delhi, and supplies it to school, college, research and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Burners products
- Economy Burner Meker (EL-B-10656)
- Bunsen Burner Pilot Flame (EL-B-10658)
- Flame Spreader (EL-B-10655)
- Teclu Burner (EL-B-10659)
- Burner Tube (EL-B-10654)
- Meker Burner (EL-B-10660)
The full range is in the Burners section of the Laboratory Equipment range.
Frequently asked questions
What is the heavy base of this Meker burner made of?
It is a heavy, wide die-cast metal base of 80 mm diameter.
How is the flame adjusted on the Meker burner with heavy base?
A rotatable air regulator around the jet controls the air drawn in with the gas.
What is the price of the Meker burner with heavy base?
Prices are not published on the website. Add the Meker burner with heavy base to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-B-10657 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Meker burner with heavy base?
Yes. Lab Exports manufactures the Meker burner with heavy base at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-B-10657.
