Portable Analog Wattmeter
Product Code : SCL-LM-11153
Quick answer: The Portable Analog Wattmeter measures electrical power in a circuit and shows it on an analog pointer and graduated scale. It is used in physics and electrical laboratories to show the relationship between voltage, current and power, and how power changes with the load. Its portable form moves easily between benches. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Value |
|---|---|
| Measured quantity | Electrical power |
| Display | Analog pointer and graduated scale |
| Configuration | Portable laboratory instrument |
The power, voltage and current ranges are not stated on this page; give the load to be measured when requesting a quote.
How it is used
Electrical power is the rate at which energy is delivered to a load. In a DC circuit P = VI; in an AC circuit the average power is P = VI cos phi, where cos phi is the power factor. A wattmeter combines both quantities in one reading: its current circuit is connected in series with the load and its voltage circuit across it, so the deflection follows the product of the two.
- Check the voltage, current and power ranges of the wattmeter against the load.
- With the supply off, connect the current terminals in series with the load.
- Connect the voltage terminals across the load.
- Switch on and read the power from the scale; change the load, for example the number of lamps, and read again.
- Compare the wattmeter reading with the product of separate voltmeter and ammeter readings.
For a resistive load such as filament lamps the two results agree closely; with an inductive load the wattmeter reads less than V x I, which introduces the idea of power factor.
Key features
- Direct reading of electrical power on an analog scale.
- Pointer movement shows at once how power changes as the load is varied.
- Portable body for use across laboratory workstations and demonstrations.
- Helps students relate voltage, current and power in one experiment.
- Suits electrical load, power and power-factor practicals under supervision.
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the portable analog wattmeter at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Lab Meters products
- Analog Voltmeter Panel Type (SCL-LM-11152)
- Analog Ammeter Panel (SCL-LM-11151)
- ESAL Spring Balance (SCL-LM-11169)
- Analog Frequency Meter (SCL-LM-11129)
- Anemometer Model (SCL-LM-11118)
- Digital Ohms Meter - 20K ohm (SCL-LM-11116)
The full range is in the Lab Meters section of the Physics Lab range.
Frequently asked questions
How is a wattmeter connected in a circuit?
Its current terminals go in series with the load and its voltage terminals across the load, so it senses both the current and the voltage.
Why can the wattmeter reading be less than voltage times current?
In an AC circuit with an inductive or capacitive load, the current and voltage are out of phase, and the true power is V x I x cos phi.
What is the price of the portable analog wattmeter?
Prices are not published on the website. Add the portable analog wattmeter to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-LM-11153 and the quantity, to receive a quotation.
Does Lab Exports manufacture the portable analog wattmeter?
Yes. Lab Exports manufactures the portable analog wattmeter at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-LM-11153.
