Centrifuge, High Speed
Product Code : EL-C-10693
Quick answer: The high speed micro centrifuge spins small tubes at 200 to 15,000 rpm, up to 21,380 x g, for specimen preparation in molecular and cellular biology: pelleting cells and DNA, sedimenting sub-cellular fractions and quick spin-downs. It has a brushless DC motor, 30 s to 99 min timer or HOLD, pulse spin and an autoclavable 24 x 1.5/2.0 mL aluminium rotor. Lab Exports manufactures it in Delhi for research and college laboratories.
Specifications
| Parameter | Specification |
|---|---|
| Speed range | 200 to 15,000 rpm, in 10 rpm steps |
| Maximum RCF | 21,380 x g, in 10 x g steps |
| Speed accuracy | ± 20 rpm |
| Run time | 30 s to 99 min, or continuous (HOLD) |
| Drive | Brushless DC motor |
| Standard rotor | 24 x 1.5/2.0 mL, high-strength aluminium, fully autoclavable |
| Rotor options | 5 mL x 18; 0.2/0.5/1.5/2 mL x 24; 0.5 mL x 36; PCR 8-strip x 4 |
| Cooling | Multi-flow air cooling |
How it is used
Micro-centrifuges handle the 0.2 to 2 mL tubes used in molecular biology, where samples are small and need high force. Setting the run by RCF rather than rpm makes a method repeatable on any rotor, because RCF = 1.118 x 10^-5 x r x rpm^2, with r the rotor radius in cm. This model can be set in 10 rpm or 10 x g steps up to 15,000 rpm or 21,380 x g.
Typical uses are pelleting bacteria and cultured cells, precipitating and washing DNA and RNA, spin-column clean-ups, and separating sub-cellular organelles or viruses in research work. The short-spin pulse key brings a tube quickly to speed to collect droplets from the lid and walls before a reaction is set up.
- Load tubes in balanced, opposite positions in the rotor; use adapters for 0.5 or 0.2 mL tubes.
- Close the lid; the interlock prevents running with the lid open.
- Set speed or RCF and run time, or choose HOLD for continuous running.
- Start the run, or press short spin for a quick pulse.
- When the rotor stops the lid releases automatically; remove the tubes.
Key features
- Brushless DC motor with speed accuracy of ± 20 rpm.
- Anti-sample-overflow rotor design helps prevent tube leaks and contamination.
- Four rotor options, with adapters for 0.5 and 0.2 mL tubes.
- Multi-flow air cooling keeps rotor temperature low, with a temperature display.
- Automatic lid release after the rotor stops, with dual interlocking safety.
- Cast casing for stability and reduced noise.
Documentation and supply
Installation instructions and a manual are supplied with the centrifuge. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the high speed micro centrifuge at its works in Laxmi Nagar, Delhi, and supplies it to research, college, clinical and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Centrifuges products
- Fixed Angle Rotor (EL-C-10692)
- Centrifuge, Clinical, Swing Out Head (EL-C-10694)
- Centrifuge, Clinical (EL-C-10695)
- Centrifuge, Mini (EL-C-10696)
- Hand Centrifuge (EL-C-10697)
- Micro Centrifuge (EL-C-10698)
The full range is in the Centrifuges section of the Laboratory Equipment range.
Frequently asked questions
What is the maximum speed and RCF?
The maximum is 15,000 rpm and 21,380 x g, adjustable in 10 rpm or 10 x g increments from 200 rpm.
Is the rotor autoclavable?
Yes. The standard 24 x 1.5/2.0 mL rotor is high-strength aluminium and fully autoclavable.
What is the price of the high speed micro centrifuge?
Prices are not published on the website. Add the high speed micro centrifuge to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-C-10693 and the quantity, to receive a quotation.
Does Lab Exports manufacture the high speed micro centrifuge?
Yes. Lab Exports manufactures the high speed micro centrifuge at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-C-10693.
