Polypropylene Ducted Fume Cupboard
Product Code : EL-LI-10777
Quick answer: The polypropylene ducted fume cupboard is a 1200 mm wide enclosure that draws fumes away from the user and exhausts them outside through a duct, used for handling hazardous chemicals in chemistry laboratories. It has a polypropylene work surface and base cabinet with doors, LED lighting and a 1000 x 630 x 1170 mm workspace. Lab Exports manufactures it in Delhi for schools, colleges and research laboratories.
Specifications
| Parameter | Specification |
|---|---|
| Type | Ducted fume cupboard, supplied with services |
| Width | 1200 mm |
| External dimensions (W x D x H) | 1200 x 805 x 2320 mm |
| Workspace dimensions (W x D x H) | 1000 x 630 x 1170 mm |
| Work surface | Polypropylene |
| Base cabinet | Polypropylene, with doors |
| Illumination | LED |
The services fitted, face velocity and duct connection are confirmed with the quotation.
How the ducted fume cupboard works
A ducted fume cupboard is connected to an extract fan and a duct that runs to the outside of the building. Air is pulled in through the front opening, sweeps across the workspace and carries fumes away up the duct, so nothing is returned to the room. Because it does not rely on a filter, a ducted cupboard handles a broader range of chemicals than a filtered unit.
The polypropylene work surface and base cabinet resist acids and corrosion, which suits routine chemistry work, and the cabinet below the work surface gives enclosed storage. LED lighting keeps the 1000 x 630 x 1170 mm workspace bright. Planning the duct route and fan is part of installation, since the cupboard only protects the user when the extract is running.
- Plan the location, duct route and extract fan before installation.
- Switch on the extract and check the airflow before starting work.
- Work with the apparatus well inside the cupboard and keep the sash as low as practical.
- Leave the extract running until all fumes have cleared, then close the sash.
Key features
- Ducted extraction that exhausts fumes outside the building
- Supplied with services
- Polypropylene work surface for chemical resistance
- Polypropylene base cabinet with doors for enclosed storage
- LED illumination of the workspace
- 1200 mm width with a 1000 mm wide workspace
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Polypropylene Ducted Fume Cupboard at its works in Laxmi Nagar, Delhi, and supplies it to school, college, research and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Laboratory Instruments products
- Polypropylene Inverted Mobile Fume Cabinet (EL-LI-10776)
- Fume Cupboard, Ductless (EL-LI-10778)
- Fume Cupboard, Ductless, Polypropylene (EL-LI-10779)
- Laboratory Drying/Warming Cabinet (EL-LI-10774)
- Vacuum Tubing (EL-LI-10780)
- Laboratory Incubator with Visibility Door (EL-LI-10773)
The full range is in the Laboratory Instruments section of the Laboratory Equipment range.
Frequently asked questions
What is the difference between a ducted and a ductless fume cupboard?
A ducted fume cupboard exhausts fumes outside through a duct and fan, while a ductless unit filters the air and returns it to the room. The ducted type does not depend on filter capacity, so it handles a wider range of chemicals.
What are the dimensions of the ducted fume cupboard?
It is 1200 mm wide, 805 mm deep and 2320 mm high overall, with a 1000 x 630 x 1170 mm workspace.
What is the price of the Polypropylene Ducted Fume Cupboard?
Prices are not published on the website. Add the Polypropylene Ducted Fume Cupboard to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-LI-10777 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Polypropylene Ducted Fume Cupboard?
Yes. Lab Exports manufactures the Polypropylene Ducted Fume Cupboard at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-LI-10777.
