Moisture Analyser
Product Code : EL-LI-10772
Quick answer: The moisture analyser determines moisture content of a sample by drying it under a halogen infrared lamp while weighing it, used for raw materials and finished products in food, cosmetics, ceramics, agriculture and construction materials. It weighs up to 160 g at 0.001 g resolution, heats from 50 to 160 °C and reports 0-100% moisture to 0.01%. Lab Exports manufactures it in Delhi for testing and research laboratories.
Specifications
| Parameter | Specification |
|---|---|
| Weighing capacity | 160 g |
| Weighing resolution | 0.001 g (0.01%) |
| Repeatability | 0.002 g |
| Linearity | ±0.003 g |
| Moisture range | 0.00% - 100% |
| Moisture readability | 0.01% |
| Dry residual range | 100.00% - 0.00% |
| Sample weight precision | 0.05% - 0.5% (2 g - 10 g samples) |
| Heat source | Halogen infrared lamp |
| Temperature sensor | PT-100 |
| Temperature range | 50 °C - 160 °C, 1 °C steps |
| Temperature compensation (2 points) | 80 °C - 150 °C |
| Temperature slew rate | 30 °C/min |
| Pan diameter | 110 mm |
| Display | LCD with backlight |
| Interface | RS232 |
| Operating temperature | 5 °C - 35 °C |
How the moisture analyser is used
Moisture analysis by drying compares the mass of a sample before and after its water is driven off. Here a halogen infrared lamp heats the sample directly on the weighing pan while the balance records the falling mass at 0.001 g resolution; the result is shown as moisture (0-100%) or as dry residue. A PT-100 platinum resistance sensor measures the drying temperature, and two-point temperature compensation between 80 °C and 150 °C keeps the heating accurate.
Because the lamp heats the sample at up to 30 °C per minute, a test is completed far sooner than in a drying oven, which makes the analyser useful for checking raw materials on arrival and finished goods before dispatch in food, cosmetics, ceramics, agriculture and building materials.
- Tare the empty 110 mm pan.
- Spread a 2 g to 10 g sample evenly over the pan.
- Set the drying temperature between 50 °C and 160 °C.
- Start the test and let the analyser dry the sample until the mass is steady.
- Read the moisture or dry residue percentage, and send it through RS232 if a record is needed.
Key features
- Halogen infrared heating with PT-100 temperature sensing
- Moisture range of 0.00% to 100% with 0.01% readability
- 160 g capacity with 0.001 g resolution
- Backlit LCD and RS232 interface
- Sturdy construction for routine testing
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Moisture Analyser at its works in Laxmi Nagar, Delhi, and supplies it to school, college, research and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Laboratory Instruments products
- Laboratory Incubator with Visibility Door (EL-LI-10773)
- Orbital Shaker, Digital (EL-LI-10770)
- Laboratory Drying/Warming Cabinet (EL-LI-10774)
- Oven, 43 litre (EL-LI-10769)
- Moisture Analyser, 200g (EL-LI-10768)
- Polypropylene Inverted Mobile Fume Cabinet (EL-LI-10776)
The full range is in the Laboratory Instruments section of the Laboratory Equipment range.
Frequently asked questions
What is the capacity and resolution of the moisture analyser?
It weighs up to 160 g with 0.001 g resolution, repeatability of 0.002 g and linearity of ±0.003 g.
What sample size gives the best precision?
Samples of 2 g to 10 g are specified, giving a sample weight precision of 0.05% to 0.5%.
Which industries use this moisture analyser?
It is used for raw materials and finished samples in food, cosmetics, ceramics, agriculture and construction materials.
What is the price of the Moisture Analyser?
Prices are not published on the website. Add the Moisture Analyser to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-LI-10772 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Moisture Analyser?
Yes. Lab Exports manufactures the Moisture Analyser at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-LI-10772.
