Tool Dynamometers
Product Code : EL-TOML-11032
Quick answer: Tool dynamometers measure the cutting forces produced during machining, so that students can check theoretical cutting force calculations against real data. Lab Exports offers lathe, milling, drilling and grinder versions, each with octagonal ring strain gauge sensing and a two or three channel digital force indicator. Lab Exports manufactures them in Delhi for engineering colleges, polytechnics and TVET institutes.
Specifications
| Item | Specification |
|---|---|
| Type | Multi-component machine tool dynamometers |
| Sensing | Octagonal ring units with strain gauges |
| Force display | Digital force indicator, two or three channel depending on version |
| Versions | Lathe, milling, drilling and grinder tool dynamometers |
| Purpose | Experimental check of theoretical cutting force calculations |
Uses
When a tool cuts metal, the force on it can be resolved into components: on a lathe, the tangential (main cutting) force, the feed force and the radial force; in drilling, the thrust and the torque. These forces set the power needed, the deflection of tool and work, and the tool wear, so they are central to machining theory.
A tool dynamometer measures these components while the machine is actually cutting. The octagonal ring is a stiff elastic element whose strain gauges respond to force in chosen directions with little cross-talk, and the digital indicator shows each component directly. Students vary speed, feed, depth of cut and work material and compare the measured forces with values from Merchant's circle or empirical formulas.
Key features
- Multi-component design measures forces during actual machining
- Octagonal ring and strain gauge sensing for repeatable readings
- Digital force indicators, two or three channel according to version
- Separate versions for turning, milling, drilling and grinding
- Cross-checks empirical and theoretical cutting force calculations
- Built for production and manufacturing engineering laboratories
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the tool dynamometer at its works in Laxmi Nagar, Delhi, and supplies it to engineering colleges, polytechnics and TVET institutes in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Theory of Machine Lab products
- Lathe Tool Dynamometers (EL-TOML-11035)
- Milling Tool Dynamometers (EL-TOML-11033)
- Drilling Tool Dynamometers (EL-TOML-11036)
- Grinder Tool Dynamometers (EL-TOML-11034)
- Dead Weight Pressure Gauge Tester (EL-TOML-11031)
- Journal Bearing Apparatus (EL-TOML-11030)
The full range is in the Theory of Machine Lab section of the Engineering Lab range.
Frequently asked questions
Which tool dynamometer versions are available?
Lathe, milling, drilling and grinder tool dynamometers, each matched to its machining operation.
How many force components can be measured?
Two or three components at the same time, depending on the version, shown on a multi-channel digital force indicator.
What is the price of the tool dynamometer?
Prices are not published on the website. Add the tool dynamometer to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-TOML-11032 and the quantity, to receive a quotation.
Does Lab Exports manufacture the tool dynamometer?
Yes. Lab Exports manufactures the tool dynamometer at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-TOML-11032.
