Cam Analysis Apparatus
Product Code : EL-TOML-11023
Quick answer: The cam analysis apparatus is used to study cam profiles and follower motion, plot displacement against cam angle and find the jump speed at which the follower leaves the cam. It includes eccentric, tangent and circular arc cams, mushroom, flat-faced and roller followers, a dial gauge and a variable speed drive. Lab Exports manufactures it in Delhi for engineering colleges, polytechnics and TVET institutes.
Specifications
| Component | Specification |
|---|---|
| Cams | Eccentric, tangent and circular arc, one each |
| Followers | Mushroom, flat-faced and roller, one each |
| Camshaft | Supported in ball bearings |
| Drive | Variable speed motor coupled to the camshaft, with speed control |
| Measurement | Dial gauge for follower displacement |
| Surface treatment | Cams and followers hardened to reduce wear |
| Power supply | 230 V stabilised AC with earthing |
| Documentation | Technical manual |
How the cam analysis experiment is done
A cam turns rotary motion into a set pattern of reciprocating motion in the follower, as in the valve gear of an engine. The shape of the cam decides the follower's displacement, velocity and acceleration over each revolution, while the follower type, mushroom, flat-faced or roller, changes the contact conditions and the wear.
At low speed the follower stays in contact with the cam. As speed rises, the inertia force during the deceleration part of the lift grows with the square of the speed, and at the jump speed it overcomes the force holding the follower down, so the follower leaves the cam surface. Finding this speed for each cam and follower pair shows why cam profile and follower mass matter in high-speed machines.
- Mount the chosen cam on the camshaft and fit a follower.
- Turn the cam by hand in equal angle steps and read the follower lift on the dial gauge.
- Plot follower displacement against cam angle to get the lift profile.
- Run the motor and raise the speed slowly until the follower is seen or heard to jump.
- Repeat for the other cams and followers and compare the profiles and jump speeds.
Key features
- Three cam profiles, eccentric, tangent and circular arc, on one set-up
- Mushroom, flat-faced and roller followers that can be swapped for comparison
- Dial gauge for plotting follower displacement against cam position
- Variable speed motor coupled to the camshaft for jump speed tests
- Hardened cams and followers to reduce wear
- Camshaft supported in ball bearings
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the cam analysis apparatus at its works in Laxmi Nagar, Delhi, and supplies it to engineering colleges, polytechnics and TVET institutes in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Theory of Machine Lab products
- Whirling of Shaft Apparatus (EL-TOML-11022)
- Vibration Lab Complete 11 Experiment (EL-TOML-11024)
- Motorised Governor Apparatus (EL-TOML-11021)
- Generation of Involute Gear Tooth Profile (EL-TOML-11025)
- Motorised Gyroscope Apparatus (EL-TOML-11020)
- Interference Undercutting (EL-TOML-11026)
The full range is in the Theory of Machine Lab section of the Engineering Lab range.
Frequently asked questions
What cam and follower types are supplied?
Eccentric, tangent and circular arc cams, with mushroom, flat-faced and roller followers, one of each.
What is jump speed in a cam experiment?
It is the speed at which the inertia of the follower overcomes the force keeping it on the cam, so the follower lifts off the cam surface.
What is the price of the cam analysis apparatus?
Prices are not published on the website. Add the cam analysis apparatus to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-TOML-11023 and the quantity, to receive a quotation.
Does Lab Exports manufacture the cam analysis apparatus?
Yes. Lab Exports manufactures the cam analysis apparatus at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-TOML-11023.
