Vernier Caliper IME Type

Product Code : SCL-AM-11188

Specifications

How to read a vernier caliper

A vernier caliper combines a fixed main scale with a sliding vernier scale. Its least count is the difference between one main scale division and one vernier scale division, or LC = value of one main scale division / number of vernier divisions. With 1 mm main scale divisions, 10 vernier divisions give 0.1 mm and 20 give 0.05 mm.

The reading is the main scale reading just before the vernier zero, plus the number of the vernier line that coincides with a main scale line multiplied by the least count. Any zero error is then removed: true reading = observed reading - zero error.

1. Close the jaws fully and check whether the vernier zero lines up with the main scale zero; note any positive or negative zero error.
2. Open the jaws with the thumb wheel, place the object between the outside jaws (or the inside jaws for a bore) and close gently.
3. Tighten the locking screw so the reading cannot shift.
4. Read the main scale, find the coinciding vernier line and work out the reading with the least count.
5. Correct for zero error and record the result; repeat at different positions and take the mean.

Typical practicals include finding the internal and external diameters of a hollow cylinder to calculate its volume, measuring a sphere or block to work out density, and measuring the depth of a beaker or test tube.

Key features

• Dual metric and imperial scales, 0-150 mm and 0-6 inches
• Laser-engraved graduations that stay legible with regular student use
• IME-type thumb wheel with spring tension for fine, smooth jaw adjustment
• Four-way measurement: outside diameter, inside diameter, depth and step
• Locking screw holds the slide while the reading is taken
• Chrome-plated steel body, stored in a velvet-lined case

Documentation and supply

A user instruction guide with basic calibration and zero-error adjustment steps is supplied with the caliper. Most Lab Exports products carry a one-year manufacturer warranty.

Lab Exports manufactures the Vernier Caliper IME Type at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.

Related Applied Mechanics products

• Newton's 1st Law Model (SCL-AM-11168)
• Newton's Second Law Model (2nd Law of Motion Apparatus) (SCL-AM-11167)
• Newton's Third Law Model (3rd Law of Motion Apparatus) (SCL-AM-11166)
• Newton's Cradle Model (SCL-AM-11165)
• Anti Gravity Cone (SCL-AM-11157)
• Hydro Power Model (SCL-AM-11156)

The full range is in the Applied Mechanics section of the Physics Lab range.

Frequently asked questions

What is the least count of the Vernier Caliper IME Type?

The metric scale reads to 0.1 mm or 0.05 mm depending on the version, and the imperial scale reads to 1/128 inch.

What can be measured with this vernier caliper?

Outside diameters and lengths with the main jaws, inside diameters with the inside jaws, depths with the depth rod, and step heights, up to 150 mm or 6 inches.

What is the price of the Vernier Caliper IME Type?

Prices are not published on the website. Add the Vernier Caliper IME Type to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-AM-11188 and the quantity, to receive a quotation.

Does Lab Exports manufacture the Vernier Caliper IME Type?

Yes. Lab Exports manufactures the Vernier Caliper IME Type at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-AM-11188.
