Simple Cup Anemometer
Product Code : EL-PMP-10407
Quick answer: A simple cup anemometer measures wind speed through the rotation of its cups: three lightweight hemispherical plastic cups on light spokes turn a central hub faster as the wind strengthens. With no meter or display, it teaches the basic principle of cup anemometry by counting turns. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Attribute | Detail |
|---|---|
| Cups | Three, lightweight hemispherical plastic |
| Mounting | Cups fixed to a central hub by lightweight spokes |
| Function | Determination of wind speed |
| Readout | None; mechanical rotor for counting revolutions |
How the cup anemometer is used
Each hemispherical cup has more drag on its open, concave side than on its rounded back, so the wind pushes harder on the cup moving downwind than on the one returning into it. That difference turns the rotor, and its rate of rotation rises roughly in proportion to the wind speed. The simple model has no counter or meter, so the speed is found by counting turns.
- Mark one cup with coloured tape so its revolutions can be counted.
- Measure the radius from the centre of the hub to the centre of a cup.
- Hold or mount the anemometer in the open wind and count revolutions of the marked cup over 30 or 60 seconds with a stopwatch.
- Work out the speed of the cups as 2 pi r N / t, where N is the number of turns in time t.
- Repeat at different places or times of day and compare the results.
The cup speed is lower than the true wind speed, so the result is best used for comparison and for discussing why instruments need calibration, which leads on to the display-type anemometers.
Key features
- Three-cup rotor, the classic arrangement for measuring wind speed.
- Lightweight hemispherical plastic cups that respond readily to moving air.
- Light spokes and a central hub keep the rotor easy to turn.
- Purely mechanical with no display, so students see the principle before using meters.
- Suited to outdoor field exercises and to classroom demonstrations with a fan.
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the simple cup anemometer at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Physics Miscellaneous Products products
- Wind Vane (EL-PMP-10406)
- Cup Anemometer with Digital Display (EL-PMP-10408)
- Cup Anemometer with Analog Display (EL-PMP-10409)
- Advanced Anemometer (EL-PMP-10410)
- CBSE Physics Lab Package (SCL-PMP-11105)
- Powell's Wave (SCL-PMP-11115)
The full range is in the Physics Miscellaneous Products section of the Physics Lab range.
Frequently asked questions
How many cups does the simple cup anemometer have?
It has three lightweight hemispherical plastic cups mounted on a central hub through light spokes.
How is wind speed found without a display?
Count the revolutions of one marked cup over a timed interval and use the cup radius to calculate the rotor speed; faster rotation means stronger wind.
What is the price of the simple cup anemometer?
Prices are not published on the website. Add the simple cup anemometer to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-PMP-10407 and the quantity, to receive a quotation.
Does Lab Exports manufacture the simple cup anemometer?
Yes. Lab Exports manufactures the simple cup anemometer at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-PMP-10407.
