Constant Level Tank
Product Code : EL-H-10403
Quick answer: The Constant Level Tank keeps a uniform flow of water through calorimeters and similar heat apparatus, whatever the pressure changes in the supply line. It is a copper vessel of 100 x 75 mm with an inlet, an outlet and a central overflow tube that fixes the water level. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Item | Specification |
|---|---|
| Material | Copper |
| Size | 100 x 75 mm diameter |
| Tubes | Water inlet, outlet and overflow |
| Level control | Central overflow tube fixes the maximum water level |
| Function | Maintains a constant water level and steady downstream flow |
How it is used
Flow-based heat experiments need water to pass through the apparatus at a rate that does not change during a reading. Mains or overhead-tank pressure varies, so the Constant Level Tank is placed between the supply and the experiment. Water is fed in slightly faster than it is drawn off; the excess spills down the central overflow tube, so the surface stays at a fixed height and the head driving the outlet flow stays constant.
- Mount the tank above the apparatus it will feed.
- Connect the supply to the inlet, the outlet to the experiment and the overflow tube to a drain.
- Open the supply until water just runs from the overflow.
- Set the outlet flow for the experiment; it then stays steady while readings are taken.
Typical uses are continuous-flow calorimetry, such as the Callendar and Barnes specific heat experiment, and the cooling-water supply of steady-state conduction experiments such as Searle's apparatus.
Key features
- Copper vessel, 100 x 75 mm, suited to repeated use with heat apparatus
- Separate tubes for water inlet, outlet and overflow
- Central overflow tube keeps the level at a fixed height
- Outlet flow does not follow pressure changes in the supply line
- Pairs with continuous-flow calorimetry and other flow experiments
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Constant Level Tank at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Heat products
- Callendar and Barne's Apparatus (Continuous Flow) (EL-H-10402)
- Joule's Mechanical Heat Experiment Apparatus (EL-H-10404)
- Joule's Calorimeter (EL-H-10401)
- Clement and Desormes Apparatus (EL-H-10405)
- Lee's and Charlton's Apparatus (EL-H-10400)
- Searle's Thermal Conductivity Apparatus (EL-H-10399)
The full range is in the Heat section of the Physics Lab range.
Frequently asked questions
What is a constant level tank used for?
To supply a uniform flow of water to calorimeters or other equipment, regardless of pressure fluctuations in the supply line.
How does the tank keep the level constant?
A central overflow tube sets the highest level the water can reach; any extra inflow drains away through it, so the head on the outlet stays the same.
What is the price of the Constant Level Tank?
Prices are not published on the website. Add the Constant Level Tank to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-H-10403 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Constant Level Tank?
Yes. Lab Exports manufactures the Constant Level Tank at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-H-10403.
Request a quote
Email [email protected] with the house code EL-H-10403 and the quantity, or add the Constant Level Tank to the Enquiry Cart with the Add To Cart button on this page. Tender buyers can also see the Tenders and OEM page.
