Decade Resistance Box, Dial Type
Product Code : EL-EAE-10284
Quick answer: The Decade Resistance Box, Dial Type gives an adjustable, known resistance set by rotary dials, with the decades connected in series. It is made in single, two, three and four dial versions with high-stability 1% film resistance elements, suitable for AC or DC circuits. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Item | Specification |
|---|---|
| Dial configurations | Single, two, three and four dials |
| Decade connection | Individual decades connected in series |
| Resistance element | High-stability 1% carbon metal film |
| Higher accuracy option | Constantan or manganin wound coil resistance |
| Current type | Suitable for AC or DC use |
How it is used
In a decade box each dial selects one of ten steps, and each dial works in steps ten times larger than the one before it. Because the decades are connected in series, the resistance between the terminals is simply the sum of the dial settings, so a value can be read straight off the dials without adding up plugs.
The dial type is convenient wherever the resistance has to be changed often during an experiment: setting the series resistance in Ohm's law and characteristic-curve practicals, balancing a bridge, or finding the resistance needed when converting a galvanometer into an ammeter or voltmeter. The film elements suit both AC and DC work, and for the highest accuracy a version with constantan or manganin wound coils is available.
- Set all dials to zero and connect the box into the circuit through its terminals.
- Turn the highest dial first to bring the resistance near the value needed.
- Adjust the lower dials in turn for the final setting.
- Read the total resistance directly from the dial positions.
Key features
- Single, two, three and four dial versions to suit the range and resolution needed
- Decades connected in series, so the total is read directly from the dials
- High-stability 1% film resistance elements
- Suitable for both AC and DC experiments
- Higher accuracy option with constantan or manganin wound coils
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the dial type decade resistance box at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Resistance Substitution Box (EL-EAE-10283)
- Post Office Box Plug Type (EL-EAE-10285)
- Resistance Box Plug Type (EL-EAE-10282)
- Resistance Box Electronic Type (EL-EAE-10286)
- Rheostat Constantine (Eureka) Wire (EL-EAE-10287)
- Rheostat Nichrome Wire Groove Type (EL-EAE-10288)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
What dial configurations are available?
Single, two, three and four dial versions of the decade resistance box are made.
Can the decade resistance box be used with AC?
Yes. The box is suitable for both AC and DC use.
What is the price of the dial type decade resistance box?
Prices are not published on the website. Add the dial type decade resistance box to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-EAE-10284 and the quantity, to receive a quotation.
Does Lab Exports manufacture the dial type decade resistance box?
Yes. Lab Exports manufactures the dial type decade resistance box at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-EAE-10284.
