Step Down Transformer
Product Code : SCL-EAE-11207
Quick answer: The Step Down Transformer converts 220-240 V AC mains to low AC voltages of 2, 4, 6, 8, 10 or 12 V, selected with a rotary dial, at up to 2 A. It powers lamps, coils and circuit boards in physics practicals and is used to show the transformer turns-ratio rule. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Value |
|---|---|
| Input voltage | 220-240 V AC, 50 Hz |
| Output voltages | 2, 4, 6, 8, 10 and 12 V AC |
| Maximum current | 2 A |
| Output selection | Rotary selector dial |
| Windings | Enamel-insulated copper |
| Output terminals | Colour-coded insulated banana sockets |
| Mains lead | Removable three-pin earthed cable |
| Indicator | Red LED power indicator |
| Enclosure | Powder-coated sheet steel |
How the transformer is used
A transformer works by mutual induction: an alternating current in the primary coil sets up a changing magnetic flux in the core, which induces a voltage in the secondary coil. For an ideal transformer Vs/Vp = Ns/Np, so a secondary with fewer turns than the primary gives a lower voltage. The selector on this unit gives six output steps from 2 V to 12 V.
- Place the transformer on a dry, level bench away from water.
- Set the selector to the lowest output and connect the load to the output sockets.
- Connect the mains lead and switch on; the LED confirms that the unit is live.
- Raise the output step by step as the experiment requires, keeping the load current at or below 2 A.
- Switch off at the mains before changing connections.
Because the output is AC, it suits lamps, heating coils, induction and electromagnet demonstrations directly; for DC experiments a rectifier or a battery eliminator is used instead.
Key features
- Six AC outputs from 2 V to 12 V in 2 V steps
- 2 A maximum output current for lamps and coils
- Rotary selector dial for quick voltage changes
- Enamel-insulated copper windings
- Colour-coded insulated output sockets for banana plugs
- Powder-coated steel case with LED power indicator and earthed mains lead
Documentation and supply
An experiment and instruction manual is supplied with the transformer. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the step down transformer at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Brass Wire (100 gm) (SCL-EAE-11209)
- Digital Panel Meter (SCL-EAE-11204)
- LDR Characteristics Apparatus (SCL-EAE-11203)
- Galvanometer (SCL-EAE-11202)
- Steam Engine Model with Dynamo (SCL-EAE-11212)
- Conversion of Galvanometer (SCL-EAE-11201)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
What output voltages does the step down transformer give?
It gives 2, 4, 6, 8, 10 and 12 V AC, selected on a rotary dial, with a maximum current of 2 A from a 220-240 V, 50 Hz mains input.
Can it be used for DC experiments?
Not directly, because the output is AC. For DC work, use a battery eliminator or a rectifier circuit between the transformer and the load.
What is the price of the step down transformer?
Prices are not published on the website. Add the step down transformer to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-EAE-11207 and the quantity, to receive a quotation.
Does Lab Exports manufacture the step down transformer?
Yes. Lab Exports manufactures the step down transformer at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-EAE-11207.
