Electric Water Bath Rectangular
Product Code : EL-WB-10812
Quick answer: The electric water bath, rectangular, is a stainless steel bath with 75 mm holes and concentric rings on top, used to heat and evaporate solutions in flasks, beakers and dishes over hot water or steam. A 1 kW heater with cut-out does the heating and tubules hold the water level. Lab Exports manufactures it in Delhi for school, college, research and industrial laboratories.
Specifications
| Component | Specification |
|---|---|
| Chamber | Stainless steel, single wall |
| Top | 75 mm holes fitted with concentric rings |
| Water level | Tubules for water level arrangement |
| Heater | 1 kW with cut-out device |
| Cable | Connector plug with 1 m of 3-core cable |
The number of holes and overall size are not listed; state the size required in the enquiry.
How it is used
This is the classic open-top laboratory water bath. Water in the chamber is heated towards boiling, and vessels rest over the holes so that hot water or steam heats their base gently. The concentric rings are lifted out one by one to match the opening to the vessel, from a small evaporating dish to a round-bottom flask, so the vessel sits securely and heat reaches it evenly.
It is used for evaporating solvents and solutions to dryness, concentrating extracts, warming flasks and melting substances that must not be heated over a naked flame. The tubules connect to a water supply and drain so the level can be kept constant during long runs, and the cut-out device on the heater adds protection against overheating.
- Fill the chamber with water to the working level, or connect the level tubules to a supply and drain.
- Remove rings until the opening suits the vessel, then set the vessel over the hole.
- Switch on the 1 kW heater and let the water come up to temperature.
- Keep the water topped up during long evaporations, and switch off before emptying.
Key features
- Single-wall stainless steel chamber that resists corrosion
- 75 mm holes with concentric rings to seat vessels of different sizes
- Tubules for a constant water level arrangement
- 1 kW heater with safety cut-out device
- Connector plug with 1 m of 3-core cable
Documentation and supply
Installation instructions and a manual are supplied with the bath. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the rectangular electric water bath at its works in Laxmi Nagar, Delhi, and supplies it to school, college, research and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Water Bath products
- Serological Water Bath (EL-WB-10811)
- Water Bath (EL-WB-10813)
- Digital Serological Water Bath (EL-WB-10810)
- Electric Water Bath (EL-WB-10814)
- Water Bath Kit for Hotplates (EL-WB-10809)
- Digital Unstirred Triple Water Bath (EL-WB-10808)
The full range is in the Water Bath section of the Laboratory Equipment range.
Frequently asked questions
What are the concentric rings for?
The rings sit in the 75 mm holes and can be removed one at a time, so flasks, beakers and evaporating dishes of different sizes sit securely over the hot water.
What is the heater rating of the rectangular water bath?
It has a 1 kW heater fitted with a cut-out device.
How is the water level kept steady?
Tubules are provided for a water level arrangement, so the bath can be connected to a supply and drain to hold a constant level.
What is the price of the rectangular electric water bath?
Prices are not published on the website. Add the rectangular electric water bath to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-WB-10812 and the quantity, to receive a quotation.
Does Lab Exports manufacture the rectangular electric water bath?
Yes. Lab Exports manufactures the rectangular electric water bath at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-WB-10812.
