Tube Roller, Variable Speed
Product Code : EL-LI-10765
Quick answer: The variable speed tube roller mixes samples by turning tubes and bottles on powered rollers while rocking them, used for gentle blending of samples, suspensions and reagents with little foaming. Its 6 rollers, each 280 mm long, run at 0-70 rpm with a 24 mm rocking amplitude and carry up to 4 kg. Lab Exports manufactures it in Delhi for university, industrial and medical laboratories.
Specifications
| Parameter | Specification |
|---|---|
| Motion | Rocking and rolling |
| Number of rollers | 6 |
| Roller length | 280 mm |
| Speed range | 0-70 rpm, variable |
| Amplitude | 24 mm |
| Maximum load | 4 kg |
| Motor | DC, brushless |
| Power | 25 W |
| Speed display | Analogue |
| Operation | Continuous |
| Dimensions (D x W x H) | 450 x 260 x 120 mm |
| Weight | 4.5 kg |
| Permissible working temperature | 5-40 °C |
How the tube roller is used
Tubes and bottles are laid across the rollers. As the rollers turn, each container spins slowly about its long axis, so the liquid washes over the whole inner wall; at the same time the rocking action, with a 24 mm amplitude, tilts the tubes so the contents run from end to end. The two motions together mix thoroughly while keeping the shear low.
That gentle action suits samples that must not be shaken hard, such as cell and particle suspensions that must stay evenly dispersed and reagents that foam. The rollers take most tube types, including bijou bottles, universal containers, centrifuge tubes and bottles, and speed is set anywhere from 0 to 70 rpm.
- Place the tubes or bottles across the rollers, spreading the load evenly up to 4 kg.
- Switch on and turn the speed control up slowly from zero.
- Set the speed on the analogue display to suit the sample and leave it running for the required time.
- Turn the speed back to zero before removing the tubes.
Key features
- Gentle but efficient rocking and rolling motion
- 6 rollers of 280 mm that fit most tube and bottle types
- Variable speed from 0 to 70 rpm
- Brushless DC motor for quiet, smooth running with reduced maintenance
- Small footprint of 450 x 260 mm for continuous bench use
Documentation and supply
Installation instructions and a manual are supplied with the apparatus. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Tube Roller, Variable Speed at its works in Laxmi Nagar, Delhi, and supplies it to school, college, research and industrial laboratories in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Laboratory Instruments products
- Vacuum Pump, Electric (EL-LI-10764)
- Thermo-Anemometer (EL-LI-10766)
- Vacuum Pump, Hand (EL-LI-10763)
- Stand for 1200mm Fume Cabinet (EL-LI-10767)
- Weighting Tray (EL-LI-10762)
- Moisture Analyser, 200g (EL-LI-10768)
The full range is in the Laboratory Instruments section of the Laboratory Equipment range.
Frequently asked questions
Which tubes can be used on the tube roller?
Most tube types, including bijou bottles, universal containers, centrifuge tubes and bottles, can be laid across its 6 rollers of 280 mm.
What is the speed range and load of the tube roller?
Speed is variable from 0 to 70 rpm, and the rollers carry a maximum load of 4 kg.
Can the tube roller run continuously?
Yes. It is rated for continuous operation within a working temperature of 5 to 40 °C.
What is the price of the Tube Roller, Variable Speed?
Prices are not published on the website. Add the Tube Roller, Variable Speed to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-LI-10765 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Tube Roller, Variable Speed?
Yes. Lab Exports manufactures the Tube Roller, Variable Speed at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-LI-10765.
