Loading Rheostat 3KW Bank
Product Code : SCL-EAE-11311
Quick answer: The Loading Rheostat 3 kW Bank is a resistive load with a stated capacity of 3 kW. It converts electrical energy into heat while a generator, alternator or other source is tested under load, so students can follow terminal voltage from no load to full load and work out regulation and efficiency. Lab Exports manufactures it in Delhi for engineering colleges, polytechnics and technical institutes.
Specifications
| Parameter | Detail |
|---|---|
| Load type | Resistive (loading rheostat bank) |
| Stated power capacity | 3 kW |
| Supplied | One Loading Rheostat 3KW Bank |
Operating voltage, current range, phase, resistance range, adjustment method and duty cycle are not listed on this page; confirm them before connection.
How the voltage regulation test is done
Every practical source has some internal impedance, so its terminal voltage falls as it delivers more current. Voltage regulation expresses that fall: regulation = (V no-load - V full-load) / V full-load x 100 percent. A resistive loading rheostat is the usual way to draw a controlled current from the machine while this is measured.
- Confirm that the source voltage, current, phase and frequency match the rating of the bank.
- With the machine stopped, set the bank to minimum load and connect it to the machine terminals through an ammeter and voltmeter.
- Run the machine to rated speed, adjust it to rated voltage at no load and record this voltage.
- Increase the load in steps up to rated current, keeping speed and excitation constant, and record voltage and current at each step.
- Reduce the load to zero before stopping the machine.
Because the bank turns up to 3 kW into heat, it needs free ventilation, sound earthing, tight terminals and suitable circuit protection, and it should never be covered while in use.
Key features
- Stated 3 kW power capacity
- Applies a real-power (resistive) load to a compatible source or machine
- Supports observation of current, voltage, power, regulation and efficiency
- Lets learners compare no-load and loaded operating conditions
- Used with generators, alternators and other set-ups after rating checks
- Suited to supervised electrical engineering and vocational exercises
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the 3 kW loading rheostat bank at its works in Laxmi Nagar, Delhi, and supplies it to engineering colleges, polytechnics and technical institutes in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Loading Rheostat 6.5KW Bank (SCL-EAE-11310)
- Loading Rheostat 1.2KW Bank (SCL-EAE-11312)
- Loading Inductor 2.5KVAR Bank (SCL-EAE-11309)
- Loading Inductor 1.2KVAR Bank (SCL-EAE-11308)
- Loading Rheostat 3.5KW Bank Three Phase (SCL-EAE-11314)
- Loading Capacitor 1.2KVAR Bank (SCL-EAE-11307)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
What is voltage regulation and how is it measured?
It is the change in terminal voltage between no load and full load, as a percentage of the full-load voltage. It is measured by loading the machine from zero to rated current at constant speed and excitation.
What safety points apply to a 3 kW loading rheostat?
It dissipates its load as heat, so it needs ventilation, earthing, secure terminals and circuit protection, and its voltage, current and duty ratings should be checked before connection.
What is the price of the 3 kW loading rheostat bank?
Prices are not published on the website. Add the 3 kW loading rheostat bank to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-EAE-11311 and the quantity, to receive a quotation.
Does Lab Exports manufacture the 3 kW loading rheostat bank?
Yes. Lab Exports manufactures the 3 kW loading rheostat bank at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-EAE-11311.
