IC Regulated Power Supply
Product Code : SCL-EAE-11292
Quick answer: The IC Regulated Power Supply is a bench DC source with IC-based linear regulation, giving 0-30 V continuously variable at up to 1 A with ripple and noise below 1 mV RMS. It powers diode, transistor, Ohm's law and trainer-board circuits in physics and electronics labs. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Value |
|---|---|
| Output voltage | 0-30 V DC, continuously variable |
| Output current | 0-1 A, continuous duty |
| Regulation | IC-based linear regulation |
| Ripple and noise | Less than 1 mV RMS |
| Output monitoring | Voltage and current meter interface |
| Output terminals | Colour-coded 4 mm shrouded safety sockets |
| Protection | Short-circuit and overload protection |
| Chassis | Powder-coated cold-rolled steel |
Connecting leads and the mains cable type are not listed as standard; state requirements in the enquiry.
How the regulated power supply is used
A linear IC regulator compares the output with an internal reference and continuously corrects it, so the set voltage stays steady when the mains input or the connected load changes. The result is a clean DC output, here with ripple and noise under 1 mV RMS, which suits semiconductor and electronics experiments where a noisy supply would distort the readings.
Because the voltage can be set anywhere from 0 to 30 V, one unit covers simple resistive circuits, forward and reverse bias of diodes, transistor biasing and Kirchhoff's law networks. Line and load regulation can themselves be studied by changing the load and noting how little the output moves.
- Check that the circuit needs no more than 30 V DC and 1 A.
- Turn the voltage control to minimum before switching on.
- Connect the circuit to the colour-coded 4 mm sockets, observing polarity.
- Switch on and raise the voltage slowly while watching the voltage and current display.
- Reduce the output to zero before disconnecting the circuit.
Key features
- 0-30 V DC, continuously variable output
- Up to 1 A, rated for continuous duty
- Ripple and noise below 1 mV RMS for sensitive electronics work
- Voltage and current meter interface for monitoring the output
- Short-circuit and overload protection
- Colour-coded 4 mm shrouded safety sockets in a powder-coated steel chassis
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the IC regulated power supply at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
