Prism Glass
Product Code : EL-LAO-10341
Quick answer: The Prism Glass is a transparent optical glass prism supplied in two forms: equilateral (60 x 60 x 60 degrees) for refraction and dispersion of light into a spectrum, and right-angle (45 x 45 x 90 degrees) for total internal reflection. Both forms come in 38 mm and 50 mm sizes. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Component | Specification |
|---|---|
| Material | Optical glass, transparent |
| Equilateral type | 60° x 60° x 60°, 38 mm and 50 mm, in superior and routine quality |
| Right-angle type | 45° x 45° x 90°, 38 mm and 50 mm |
| Uses | Dispersion, refraction and reflection of light |
How it is used
The two shapes teach different ideas. An equilateral prism refracts light at both faces and, because the refractive index of glass is greater for violet than for red, spreads white light into a spectrum; it is also the standard prism for finding the refractive index of glass from the angle of minimum deviation. A right-angle prism is used for total internal reflection: light entering one short face meets the hypotenuse at 45 degrees, beyond the critical angle of glass of about 42 degrees, and is turned through 90 degrees, or through 180 degrees when it enters by the hypotenuse face.
- For dispersion, direct a narrow beam of sunlight or lamp light at one face of the equilateral prism and catch the spectrum on a white screen.
- For refractive index, trace rays through the prism by the pin method, find the minimum deviation Dm and use mu = sin((A + Dm)/2) / sin(A/2) with A = 60 degrees.
- For total internal reflection, send a ray normally into a short face of the right-angle prism and watch it leave the other short face turned through 90 degrees.
- Turn the right-angle prism so that light enters the hypotenuse and observe the ray sent back through 180 degrees, as in binoculars and periscopes.
Key features
- Transparent optical glass.
- Equilateral 60 x 60 x 60 degree prisms for dispersion and minimum deviation.
- Right-angle 45 x 45 x 90 degree prisms for total internal reflection.
- 38 mm and 50 mm sizes in both shapes.
- Equilateral type offered in superior and routine quality grades.
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the glass prism at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Light and Optics products
- Acrylic Prism (EL-LAO-10340)
- Hand Lens with White Plastic Handle (EL-LAO-10342)
- Prism Calcite/Quartz (EL-LAO-10339)
- Hand Lens with Black Plastic Case (EL-LAO-10343)
- Prism Different Angle (EL-LAO-10338)
- Double Lens Folding Pocket Magnifier (EL-LAO-10344)
The full range is in the Light and Optics section of the Physics Lab range.
Frequently asked questions
What is the difference between the equilateral and the right-angle glass prism?
The equilateral 60-degree prism is used for refraction, dispersion and minimum deviation; the right-angle 45-45-90 prism turns light through 90 or 180 degrees by total internal reflection.
What sizes is the glass prism available in?
38 mm and 50 mm, for both the equilateral and the right-angle type.
What is the price of the glass prism?
Prices are not published on the website. Add the glass prism to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-LAO-10341 and the quantity, to receive a quotation.
Does Lab Exports manufacture the glass prism?
Yes. Lab Exports manufactures the glass prism at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-LAO-10341.
