Digital Panel Meter
Product Code : SCL-EAE-11204
Quick answer: The Digital Panel Meter is a panel-mounting instrument that shows a selected electrical quantity, such as voltage or current, as a direct numerical reading. It is fitted into circuit trainers, power-supply panels and demonstration boards so students can record values without reading an analogue scale. The quantity and range are chosen per model. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Detail |
|---|---|
| Type | Digital electrical measuring instrument, panel-mounting |
| Function | Numerical display of one selected electrical quantity |
| Quantity measured | Voltage, current, resistance, frequency or another parameter, according to the model chosen |
| Connections | Integrated display with connection terminals |
State the quantity, range and supply voltage needed when enquiring; these fix the model supplied.
How it is used
A digital panel meter converts its input into a number on a digital display, so a reading is taken directly instead of judging a pointer against a scale. That removes parallax error and makes it easy for students to note values in an observation table while they change the voltage, current or load in a circuit.
- Choose the model for the quantity and range required.
- Mount the meter in the panel cut-out of the trainer or power-supply unit.
- Wire the input and supply terminals as shown in the connection diagram.
- Switch on and check the reading against a known source before using it in practicals.
Typical uses include voltage and current displays on circuit trainers, monitoring the output of laboratory power supplies, and Ohm's law and basic circuit experiments where readings change step by step.
Key features
- Direct numerical reading with no pointer or parallax to interpret
- Quantity and range selected to suit the application
- Panel-mounting format for trainers, control panels and experimental boards
- Readings go straight into observation tables
- Reusable across practical sessions when used within its rated input
Documentation and supply
A connection diagram or instruction sheet is supplied with the meter. Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the digital panel meter at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
