Two Way Plug Key
Product Code : SCL-EAE-11288
Quick answer: The Two Way Plug Key has two manually operated, removable plug contacts. Inserting or removing either plug makes or breaks a selected connection, so one branch of a circuit can be switched without disturbing the rest, for example to run a lamp or meter branch on its own. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Detail |
|---|---|
| Switching capacity | Two manually operated plug contacts |
| Primary function | Making or breaking selected electrical connections |
| Included | Two removable plug contacts |
The internal connection pattern and electrical rating are not listed on this page; ask for the terminal diagram with the quotation.
How the two way plug key is used
Each plug of the two way key controls its own contact: pushed in, it closes that connection; pulled out, it opens it. Having both contacts on one base lets the experimenter control two connections from one place, which suits circuits where a branch must be switched in and out while the main supply stays connected.
Typical classroom uses include showing that a lamp in one parallel branch can be switched off while another stays lit, and bringing a meter or load into the circuit only for the moment of a reading. The exposed plugs and terminals make it easy for teachers to relate the key symbol in a circuit diagram to the real device.
- Place the plug key on a clean, dry, stable bench.
- Identify the terminals and plug contacts before connecting any leads.
- With the supply off, connect the key into the branches that need switching.
- Insert or remove each plug as the experiment requires and observe the lamps or meters.
Key features
- Two removable plug contacts on one base
- Clear make-and-break action shows changes in continuity
- Switches a selected branch without rearranging the whole circuit
- Exposed plugs and terminals for easy identification
- Connects with low-voltage supplies, meters, loads and leads
- Links circuit-symbol theory to a physical switching device
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the two way plug key at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- One Way Plug Key (SCL-EAE-11287)
- Reversing Key / Commutator (SCL-EAE-11286)
- Four Way Plug Key (SCL-EAE-11285)
- Rheostat 6 Inches (SCL-EAE-11284)
- IC Regulated Power Supply (SCL-EAE-11292)
- Tapping Key (SCL-EAE-11283)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
How is a two way plug key different from a one way plug key?
A one way key has a single plug and controls one circuit path. The two way key has two plug contacts, so two selected connections can be made or broken from the same unit.
Are leads and meters included with the two way plug key?
The listed supply is the key with its two plugs. Connecting leads, a power supply, lamps and meters are not listed as included and can be added to the same enquiry.
What is the price of the two way plug key?
Prices are not published on the website. Add the two way plug key to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-EAE-11288 and the quantity, to receive a quotation.
Does Lab Exports manufacture the two way plug key?
Yes. Lab Exports manufactures the two way plug key at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-EAE-11288.
