Rheostat 10 Inches
Product Code : SCL-EAE-11281
Quick answer: The Rheostat 10 Inches is a sliding-contact variable resistor of nominal 10-inch size. Moving the slider changes the active length of resistance wire, so the unit controls current in series circuits or provides a variable voltage as a potential divider in school and college practicals. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Detail |
|---|---|
| Apparatus type | Sliding variable resistor |
| Stated size | 10 inches |
| Adjustment method | Movable sliding contact |
| Resistance element | Integrated, with electrical connection terminals |
| Primary function | Variable resistance and circuit-current control |
Resistance in ohms and permissible current are not stated on this page; include them in the enquiry so the right unit is quoted.
Two ways to connect the rheostat
As a variable resistor, the rheostat goes in series with the load. One end terminal and the slider are used, so moving the slider adds or removes resistance wire and the current falls or rises accordingly.
As a potential divider, the whole winding is connected across the supply and the output is taken between one end and the slider. The output voltage then varies from nearly zero up to the supply voltage as the slider travels, which is useful when a component must be tested from zero volts upwards, as in lamp or diode characteristic studies.
- Place the rheostat on a dry, stable, non-conductive bench.
- Inspect the resistance element, slider and terminals for damage before wiring.
- Choose the variable-resistor or potential-divider connection and wire it with the supply switched off.
- Set the slider for maximum resistance, or minimum output voltage, then switch on and adjust gradually.
Key features
- Nominal 10-inch size for bench demonstrations and student practicals
- Movable sliding contact for continuous adjustment
- Usable as a series current controller or as a potential divider
- Electrical connection terminals for meters, supplies and circuit components
- Integrated resistance element shows the wire-length principle clearly
- Suitable for repeated use within its rating
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the 10-inch rheostat at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Rheostat 12 Inches (SCL-EAE-11280)
- Rheostat 8 Inches (SCL-EAE-11282)
- Sliding Rheostat Dual Tube (SCL-EAE-11279)
- Tapping Key (SCL-EAE-11283)
- Resistance Box 100 Ohms (SCL-EAE-11278)
- Rheostat 6 Inches (SCL-EAE-11284)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
What is the difference between using a rheostat as a variable resistor and as a potential divider?
As a variable resistor it sits in series and changes the current. As a potential divider its full winding is across the supply and the slider taps off a voltage that can be varied from near zero upwards.
Which experiments use the 10-inch rheostat?
Ohm's law, resistance-current relationships, current control through lamps, coils and resistive loads, and series-circuit measurement exercises.
What is the price of the 10-inch rheostat?
Prices are not published on the website. Add the 10-inch rheostat to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-EAE-11281 and the quantity, to receive a quotation.
Does Lab Exports manufacture the 10-inch rheostat?
Yes. Lab Exports manufactures the 10-inch rheostat at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-EAE-11281.
