Circuit Board Senior
Product Code : EL-EAE-10293
Quick answer: The Circuit Board Senior is a 3 V DC practical board on which students build, control and measure simple circuits. Beyond the cell holder, bulb holder, fan and fuse, it adds a toggle switch, buzzer, rheostat and multimeter, so current can be varied and readings taken during the experiment. Lab Exports manufactures it in Delhi for schools and colleges.
Specifications
| Item | Specification |
|---|---|
| Board type | Single sided |
| Operating voltage | 3 V DC |
| Supply | Cell holder |
| Control | Toggle switch, rheostat |
| Output devices | Bulb holder, fan, buzzer |
| Protection | Fuse |
| Measurement | Multimeter |
| Wiring | Connectors |
How the board is used in teaching
The senior board takes circuit work a step beyond switching a bulb on and off. With the rheostat in series, students can dim the bulb or slow the fan and see that adding resistance reduces the current. The multimeter lets them measure the voltage across a component and the current through it, turning observations into readings that can be tabulated and compared.
Three kinds of output device, a bulb, a fan and a buzzer, show electrical energy converted to light, motion and sound. The fuse and toggle switch reinforce the ideas of protection and control that come up again in lessons on household wiring.
- Build a series loop of cell holder, toggle switch, rheostat and bulb holder.
- Set the multimeter to a suitable range and connect it across the bulb as a voltmeter, or in series as an ammeter.
- Move the rheostat slider and record the meter reading at each setting, noting the bulb brightness.
- Replace the bulb with the fan or buzzer and repeat to compare the devices.
Key features
- 3 V DC operation from a cell holder, suited to student practical work.
- Rheostat for varying the current in the circuit.
- Multimeter for measuring voltage and current during experiments.
- Bulb holder, fan and buzzer as three different output devices.
- Fuse and toggle switch to teach circuit protection and control.
- Single-sided board with connectors for quick changes between circuits.
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Circuit Board Senior at its works in Laxmi Nagar, Delhi, and supplies it to schools and colleges in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Circuit Board Junior (EL-EAE-10292)
- Hoffman Voltameter (EL-EAE-10294)
- Pencil Jockey (EL-EAE-10291)
- Potentiometer with Jockey Pencil (EL-EAE-10290)
- Meter Bridge or Wheatstone Bridge with Pencil Jockey (EL-EAE-10289)
- Rheostat Nichrome Wire Groove Type (EL-EAE-10288)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
How is the Circuit Board Senior different from the Junior board?
The Senior board adds a buzzer, toggle switch, rheostat and multimeter, so students can vary the current and take measurements as well as build basic circuits.
Can current and voltage be measured on the Circuit Board Senior?
Yes. The multimeter included with the board is used to read the voltage across, and the current through, components in the circuit.
What is the price of the Circuit Board Senior?
Prices are not published on the website. Add the Circuit Board Senior to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code EL-EAE-10293 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Circuit Board Senior?
Yes. Lab Exports manufactures the Circuit Board Senior at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code EL-EAE-10293.
