MR66 Moving Coil Meter
Product Code : SCL-LM-11291
Quick answer: The MR66 Moving Coil Meter is a DC moving-coil meter with a 65 mm scale and ±2% FSD accuracy, supplied as an ammeter, voltmeter or centre-zero galvanometer with the range chosen to suit the practical. Students use it for Ohm's law, series and parallel circuits and electromagnetic induction. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Component | Specification |
|---|---|
| Movement | Moving coil |
| Scale length | 65 mm |
| Accuracy | ±2% of full-scale deflection |
| Configurations | Ammeter, voltmeter or centre-zero galvanometer |
| Range | Selected to suit the configuration ordered |
| Pointer | Knife-edge |
| Zero | Mechanical zero adjustment |
| Cabinet | ABS plastic |
| Terminals | Brass |
How it is used
In a moving-coil meter a coil pivoted in the field of a permanent magnet turns when current flows, against a controlling spring, so the pointer deflection is proportional to the current and the scale is linear. The same movement serves three roles: with a low-value shunt it becomes an ammeter, with a high-value series resistance a voltmeter, and with its zero in the centre of the scale a galvanometer that shows the direction of current.
- Check the configuration and range marked on the dial before connecting.
- Set the pointer on zero with the mechanical zero adjuster.
- Connect an ammeter in series, a voltmeter across the component, or the galvanometer between the points to be compared, observing polarity.
- Read with the eye directly over the knife-edge pointer to avoid parallax.
As a centre-zero galvanometer, the meter shows the direction of the induced current when a magnet is pushed into and pulled out of a coil, a standard demonstration of Faraday's and Lenz's laws.
Key features
- 65 mm scale for clear readings on the student bench.
- Accuracy of ±2% of full-scale deflection.
- Available as ammeter, voltmeter or centre-zero galvanometer.
- Knife-edge pointer for precise alignment with the scale.
- Mechanical zero adjustment to set the pointer before use.
- ABS plastic cabinet with brass terminals.
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the MR66 moving coil meter at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
