Windmill Model Kit
Product Code : SCL-AM-11321
Quick answer: The Windmill Model Kit is a renewable energy demonstration model in which moving air acting on the blades turns a rotor, the working principle of a wind turbine. Teachers use it to explain wind power and energy conversion and to compare wind with solar and hydro sources. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Item | Specification |
|---|---|
| Catalogue name | Windmill Model |
| Category | Physics laboratory equipment - renewable energy demonstration model |
| Primary principle | Airflow producing rotational motion |
| Use | Teacher demonstrations, student observation and STEM activities |
Construction, blade arrangement and any generator, meter or leads in the kit are listed on the quotation; email [email protected] for the current kit contents.
How the model is used in teaching
Each blade of a windmill is set at an angle to the oncoming air. Air striking the blade is deflected, and by Newton's third law the blade is pushed the opposite way; the part of that push acting around the axle makes the rotor turn. The faster the air moves, the greater the force on the blades and the faster the rotor spins.
No wind machine can capture all the kinetic energy of the air passing through it, because the air must keep moving to leave the blades. The theoretical maximum, known as the Betz limit, is 16/27, or about 59 per cent of the energy in the wind. This is a useful discussion point when students compare wind with solar and hydro power, including why wind output varies with the weather and why turbines are sited on high, open ground.
- Place the model securely on a flat, dry laboratory table.
- Check that the blades and rotor turn freely.
- Direct a steady airflow from a fan at the blades and observe the rotation.
- Vary the airflow and note the change in rotor speed, linking it to wind speed in real turbines.
Key features
- Visible model of how airflow produces rotational motion
- Introduces wind power as a renewable, alternative energy source
- Supports discussion of kinetic, mechanical and electrical energy in a wind turbine
- Easier to follow than diagrams alone in physics and STEM lessons
- Works alongside solar and hydro models for comparative renewable energy teaching
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Windmill Model Kit at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Applied Mechanics products
- Steam Engine Model with Boiler (SCL-AM-11275)
- Petrol Engine Model Four Stroke (SCL-AM-11274)
- Inclined Plane Apparatus (SCL-AM-11224)
- DCC Copper Wire (100gm) (SCL-AM-11223)
- Windmill Model - Small (SCL-AM-11220)
- Vernier Caliper IME Type (SCL-AM-11188)
The full range is in the Applied Mechanics section of the Physics Lab range.
Frequently asked questions
What does the windmill model kit demonstrate?
It shows how moving air acting on angled blades makes a rotor turn, the principle by which wind turbines extract energy from the wind.
Why can a wind turbine not use all the energy in the wind?
The air must keep flowing away from the blades, so some kinetic energy always remains in it. The Betz limit puts the theoretical maximum at about 59 per cent.
What is the price of the Windmill Model Kit?
Prices are not published on the website. Add the Windmill Model Kit to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-AM-11321 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Windmill Model Kit?
Yes. Lab Exports manufactures the Windmill Model Kit at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-AM-11321.
Request a quote
Email [email protected] with the house code SCL-AM-11321 and the quantity, or add the Windmill Model Kit to the Enquiry Cart with the Add To Cart button on this page. Tender buyers can also see the Tenders and OEM page.
