Transistor Characteristics Apparatus (Socket Type)
Product Code : SCL-EAE-11330
Quick answer: The Transistor Characteristics Apparatus (Socket Type) is used to plot the input and output characteristics of a bipolar junction transistor and estimate its current gain. The transistor sits in a socket, so it can be replaced or swapped for comparison without soldering. Lab Exports manufactures it in Delhi for schools, colleges and universities.
Specifications
| Parameter | Detail |
|---|---|
| Device studied | Bipolar junction transistor |
| Device mounting | Socket type |
| Equipment category | Semiconductor characteristics laboratory apparatus |
| Primary experiments | Input characteristics, output characteristics and current-gain study |
| Brand | Lab Exports |
Transistor polarity, circuit configuration, compatible package and meter ranges are confirmed with each quotation.
How the transistor characteristics experiment is done
A bipolar junction transistor is a current-controlled device: a small input current at the base controls a larger output current in the collector circuit. Its behaviour is summed up in two sets of graphs. The input characteristic relates input current to input voltage, and the output characteristics show output current against output voltage for several fixed input currents.
Mounting the transistor in a socket rather than soldering it in place has a practical teaching benefit. A damaged device can be replaced quickly, and a class can insert different compatible transistors to compare their curves and current gain on the same circuit.
- Insert a compatible transistor into the socket, matching each lead to its marked terminal.
- Keep the supplies at minimum and connect the meters as shown on the apparatus.
- Record input current at a series of input voltages with the output voltage held constant.
- Set a fixed input current and record output current as the output voltage is varied; repeat for other input currents.
- Plot the characteristic curves and estimate current gain from the readings.
Key features
- Socket-mounted transistor can be inserted and replaced without soldering
- Input-characteristic study of input current against input voltage
- Output-characteristic study at selected input-current values
- Helps learners identify cutoff, active and saturation behaviour
- Compatible transistors can be compared on the same circuit using the replaceable socket
Documentation and supply
Most Lab Exports products carry a one-year manufacturer warranty.
Lab Exports manufactures the Transistor Characteristics Apparatus (Socket Type) at its works in Laxmi Nagar, Delhi, and supplies it to schools, colleges and universities in India and 60+ countries, handling the export documents for each shipment. More about the company is on the About Lab Exports page.
Related Electrical and Electronics products
- Transistor Characteristics Apparatus (SCL-EAE-11329)
- Digital Transistor Characteristics Apparatus (SCL-EAE-11331)
- Digital Zener Diode Apparatus (SCL-EAE-11328)
- Battery Eliminator (Socket) (SCL-EAE-11332)
- 6 in 1 Logic Gate Apparatus (SCL-EAE-11327)
- Battery Eliminator 2-12V 2A (SCL-EAE-11333)
The full range is in the Electrical and Electronics section of the Physics Lab range.
Frequently asked questions
What is the advantage of the socket type transistor characteristics apparatus?
The transistor is held in a socket, so it can be replaced or exchanged for another compatible device without soldering, which suits comparison experiments and long-term lab use.
Which transistor operating regions can be studied?
From the output characteristics students identify the cutoff, active and saturation regions of the bipolar transistor and estimate its current gain.
What is the price of the Transistor Characteristics Apparatus (Socket Type)?
Prices are not published on the website. Add the Transistor Characteristics Apparatus (Socket Type) to the Enquiry Cart with the Add To Cart button on this page, or email [email protected] with the house code SCL-EAE-11330 and the quantity, to receive a quotation.
Does Lab Exports manufacture the Transistor Characteristics Apparatus (Socket Type)?
Yes. Lab Exports manufactures the Transistor Characteristics Apparatus (Socket Type) at its works at 11/315, Lalita Park, Laxmi Nagar, Delhi 110092, under house code SCL-EAE-11330.
