Induced Current Apparatus

Product Code : SCL-M-11342

 The apparatus supports direct observation of electromagnetic induction. A magnet, coil or other magnetic component is moved relative to a conducting coil, and the resulting electrical response is observed using the supplied indicator or a compatible measuring instrument.

The setup allows students to compare the effects of motion direction, motion speed and magnetic orientation. The coil construction, winding count, magnetic components, indicator type, terminal format, base material and overall dimensions must be confirmed from the approved Lab Exports technical datasheet.

Key Features

Direct induction demonstration: Shows that a changing magnetic flux can produce an induced current.

Faraday’s law study: Helps relate the magnitude of the observed response to the rate of flux change.

Lenz’s law observation: Supports comparison of current direction when the magnetic motion is reversed.

Hands-on operation: Allows students to move the magnet or coil and observe the electrical response immediately.

Variable experiment conditions: Enables comparison of motion speed, direction and magnetic-pole orientation.

Accessible connections: Coil terminals or sockets permit connection to the supplied indicator [terminal type confirm].

Classroom value: Suitable for supervised electricity, magnetism and electromagnetic-induction practicals.

Reusable apparatus: Supports repeated demonstrations without consumable experimental materials.

Technical Specifications

What's Included in the Kit

1 × Induced Current Apparatus

Induction coil or coil assembly [confirm quantity]

Permanent magnet or magnetic assembly [confirm type and quantity]

Galvanometer or current indicator

Connecting leads [confirm quantity and connector type]

Support stand, guide or mounting base

Experiment instructions

The final contents must be checked against the approved quotation and packing list.

Applications / Uses

Demonstrating electromagnetic induction in a conducting coil.

Showing that relative motion is required to produce an induced response.

Comparing induced-current direction for opposite magnet movements.

Investigating the effect of faster and slower magnetic motion.

Demonstrating the effect of reversing magnetic polarity.

Teaching Faraday’s law and Lenz’s law through observation.

Introducing the operating principle of generators and dynamos.

How to Use the Induced Current Apparatus

Place the apparatus on a stable, dry laboratory bench.

Connect the induction coil to the supplied indicator according to the approved diagram.

Check that the indicator is at zero before beginning the experiment.

Move one pole of the magnet toward the coil and observe the indicator.

Hold the magnet stationary and note whether the indication returns to zero.

Move the magnet away from the coil and compare the direction of deflection.

Repeat the procedure at different speeds and with the opposite magnetic pole.

Record the observations and relate them to Faraday’s and Lenz’s laws.

Safety note: Keep strong magnets away from sensitive electronics, magnetic storage media and medical implants. Do not strike, heat or drop the magnet, and connect only meters with compatible ranges.

Care & Maintenance

Store the magnet and coil in a dry cabinet away from moisture and metal debris.

Clean the apparatus with a soft, dry cloth and avoid solvents on coil insulation.

Inspect terminals, leads and winding insulation before each practical session.

Handle magnets carefully to prevent chipping, impact damage or unintended attraction to metal objects.

Why Choose Lab Exports

Lab Exports manufactures, supplies and exports scientific and educational laboratory equipment for institutional use. Its portfolio includes physics apparatus, electrical and electronics trainers, magnetism equipment, science kits and STEM teaching products. The company supports international procurement and OEM supply requirements. Buyers should request the model-specific datasheet, packing list and applicable documentation before ordering.

Frequently Asked Questions

What is an Induced Current Apparatus used for?

It is used to demonstrate that changing the magnetic flux through a coil produces an induced electromotive force and, in a closed circuit, an induced current.

Does the apparatus demonstrate Faraday’s law?

Yes. Students can observe that faster magnetic movement generally produces a larger indication because the magnetic flux changes more rapidly.

How does it demonstrate Lenz’s law?

The indicator deflects in opposite directions when the magnet is moved toward and away from the coil. This shows that the induced current opposes the change that produces it.

Does it require an external power supply?

A basic induction experiment generates its own small electrical response through relative motion. The exact supplied configuration and any external power requirements must be confirmed.

Is the apparatus suitable for school laboratories?

Yes. It is suitable for supervised magnetism and electricity practicals in secondary schools, colleges, polytechnics and teacher-training laboratories.

What should buyers confirm before ordering?

Confirm the coil winding, magnet type, indicator range, terminal format, accessories, dimensions, product code and product-specific documentation.

Request the verified specification and packing list from Lab Exports, or explore the electrical and electronics laboratory equipment range, magnetism laboratory equipment, the wider physics laboratory equipment collection and the related Dynamo Model AC DC.
